Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
Sick DS35-B15521 Laser Distance Sensor
SICK

Sick DS35-B15521 Laser Distance Sensor

Product SKU: NTSSEN00761
Available:
Only 5 items in stock
5 items in stock
In stock
Pre-order
Out of stock
  • Brand : Sick
  • Model : DS35-B15521
  • Part No.: 1057654
  • Supply voltage : DC 12 V ... 30 V
  • Switching output : PNP/NPN
  • Connection type : Male connector
  • Warranty: 12 Months
Rs. 23,250.00
Rs. 28,785.00

+ GST @18% = Rs. 27,435.00

Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Specifications
  • Shipping & Returns

Sick DS35-B15521 Laser Distance Sensor

The Sick DS35-B15521 Laser Distance Sensor (1057654) is a high-precision measurement device designed for accurate distance measurement in industrial automation and monitoring applications. It features a measuring range from 50 mm up to 12,000 mm, allowing reliable detection of objects over long distances.

The sensor uses a Class 1 visible red laser with a light spot size of 15 mm × 15 mm, providing precise and stable measurement performance. With a resolution of 100 µm and repeatability of ≥0.5 mm, it ensures accurate data for positioning, object detection, and level measurement tasks.

The device supports push-pull output (PNP/NPN) and offers flexible integration with control systems. Designed with a durable ABS/PC housing and IP65/IP67 protection, the sensor performs reliably in harsh environments. Its adjustable response time and switching frequency enable efficient operation in various industrial processes.


Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, it’s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it’s important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on this site are the property of their respective owners. They are used solely for identification purposes and do not imply any endorsement or affiliation with our company.

IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!


Facebook, YouTube,


Model NumberDS35-B15521
Part No.1057654
BrandSICK
Operating PrincipleLaser Distance Sensor
Measuring range50 mm ... 12,000 mm, 90% remission factor
TargetNatural objects
Resolution100 µm
Repeatability≥ 0.5 mm
Measurement accuracyTyp. ± 10 mm
Response time4.5 ms ... 192.5 ms, 4.5 ms / 12.5 ms / 24.5 ms / 48.5 ms / 192.5 ms
Switching frequency166 Hz/50 Hz/25 Hz/12 Hz/3 Hz
Output time2 ms ... 64 ms, 2 ms/4 ms/8 ms/16 ms/64 ms
Light sourceLaser, red
Type of lightVisible red light
Typ. light spot size (distance)15 mm x 15 mm
Normative referenceIEC 60825-1:2014, EN 60825-1:2014
Laser class1
Average laser service life (at 25 °C)100,000 h
MTTFD101 years
DCavg0%
FunctionProcess data, parameterization, diagnosis
Data transmission rate38.4 kbit/s
Number2
TypePush-pull: PNP/NPN
FunctionOutput Q2, adaptable: digital output/Q1 not/deactivated
Maximum output current IA≤ 100 mA
Hysteresis0 mm ... 11,950 mm
Supply voltage UBDC 12 V ... 30 V
Power consumption≤ 1.7 W
Ripple≤ 5 Vpp
Initialization time≤ 500 ms
Warm-up time≤ 20 min
DisplayLEDs
Enclosure ratingIP65

IP67
Protection classIII
Connection typeMale connector
Dimensions (W x H x D)32 mm x 58.67 mm x 42.7 mm
Housing materialPlastic (ABS/PC)
Window materialPlastic (PMMA)
Ambient temperature, operation–30 °C ... +55 °C, Uv ≤ 24 V
Ambient temperature, storage–40 °C ... +75 °C
Max. rel. humidity (not condensing)≤ 95 %
Vibration resistanceEN 60068-2-6, EN 60068-2-64
Shock resistanceEN 60068-2-27
Country of originGermany
