Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic EX-11A-PN Photoelectric Sensor
Panasonic

Panasonic EX-11A-PN Photoelectric Sensor

Product SKU: NTSSEN00184
Available:
Only 19 items in stock
19 items in stock
In stock
Pre-order
Out of stock
  • Brand : Panasonic
  • Supply Voltage : 12 to 24 V DC ±10 % Ripple P-P 10 % or less
  • Output : PNP open-collector transistor
  • Connecting method : Cable 2 m 6.562 ft long
  • Warranty : 12 Months
Rs. 3,135.00
Rs. 4,250.00
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Specifications
  • Shipping & Returns

Panasonic EX-11A-PN Photoelectric Sensor

The Panasonic EX-11A-PN Photoelectric Sensor, compliant with EMC Directive EN 60947-5-2 and RoHS Directive, features a sensing range of 150 mm and a minimum sensing object size of ø1 mm, making it suitable for various industrial applications. It operates on a supply voltage of 12 to 24 V DC with minimal current consumption, ensuring energy efficiency.

The Panasonic EX-11A-PN Photoelectric Sensor PNP open-collector transistor output, with short-circuit protection, offers reliable performance and easy integration into control systems, while its IP67 rating provides protection against dust and water ingress. With a response time of 0.5 ms or less, the EX-11A-PN provides fast and accurate detection, complemented by its stability indicator with a green LED for monitoring light reception conditions.

It withstands ambient temperatures ranging from -25 to +55 ℃ and offers vibration resistance up to 500 m/s2 acceleration (50 G approx.), ensuring durability in harsh environments. Additionally, its cable extension capability of up to 50 m allows for flexible installation, supported by UL certification and Korea’s S-mark certification, assuring quality and safety. Made in Japan, the sensor weighs approximately 20 g (net weight for each emitter and receiver) and comes with mounting screws for easy installation.

Our engineers acts wisely inputted all the required details of this sensor in accordance with the datasheet. Nevertheless, it’s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it’s important to remain cautious. Inaccuracies can still occur nonetheless.

IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!

Facebook, YouTube,


Product NumberEX-11A-PN
Part NumberUEX11APN
CE Marking Directive Compliance• EMC Directive: EN 60947-5-2
• RoHS Directive
• ISO 13849-1 (Category 1, PLc)
(Conformed from Dec 2021 production)
Sensing Range150 mm / 5.906 in
Min. Sensing ObjectØ1 mm (0.039 in) opaque object (Completely beam interrupted at 150 mm / 5.906 in)
Hysteresis-
Repeatability (Perpendicular to Sensing Axis)0.05 mm / 0.002 in or less
Supply Voltage12 to 24 V DC ±10% Ripple P-P 10% or less
Current ConsumptionEmitter: 10 mA or less
Receiver: 10 mA or less
OutputPNP open-collector transistor
- Max sink current: 50 mA
- Applied voltage: 30 V DC or less (between output & 0 V)
- Residual voltage: 2 V or less (at 50 mA), 1 V or less (at 16 mA)
Output Utilization CategoryDC-12 or DC-13
Output Short-Circuit ProtectionIncorporated
Response Time0.5 ms or less
Operation IndicatorOrange LED (ON when output is ON)
Incident Beam Indicator-
Stability IndicatorGreen LED (ON under stable light/dark condition)
Pollution Degree3 (Industrial environment)
ProtectionIP67 (IEC)
Ambient Temperature-25 to +55 °C (-13 to +131 °F), Storage: -30 to +70 °C (-22 to +158 °F) (No dew condensation or icing allowed)
Ambient Humidity35 to 85% RH, Storage: 35 to 85% RH
Ambient IlluminanceIncandescent light: 3,000 lx or less at receiving face
Voltage Withstandability1,000 V AC for 1 min between all supply terminals & enclosure
Insulation Resistance20 MΩ or more (250 V DC megger, terminals connected to enclosure)
Vibration Resistance10 to 500 Hz, 3 mm (0.118 in) double amplitude (20 G max) in X, Y, Z directions, 2 hrs each
Shock Resistance500 m/s² (≈50 G) in X, Y, Z directions, 3 times each
Emitting ElementRed LED (680 nm, modulated)
MaterialEnclosure: Polyethylene terephthalate
Lens: Polyalylate
Cable0.1 mm² 3-core (emitter: 2-core) cabtyre cable, 2 m (6.562 ft) long
Cable ExtensionUp to 50 m (164 ft) with ≥0.3 mm² cable (emitter & receiver)
Note: For safety applications, ≤30 m (98.425 ft)
AccessoryMounting screws: 1 set
CertificationUL certification, Korea S-mark certification
Country of OriginJapan
