28% Rs. 3,015.00
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze HT25C.XL/4P-M12 Diffuse Sensor
Leuze

Leuze HT25C.XL/4P-M12 Diffuse Sensor

Product SKU: NTSSEN00235
Available:
Only 6 items in stock
6 items in stock
In stock
Pre-order
Out of stock
  • Brand : Leuze
  • Supply Voltage :  10 – 30 V, DC
  • Open-circuit current : 0 … 20 mA
  • Output 1 switching element : Transistor, PNP
  • Type of connection : M12 Connector 4pins
  • Warranty : 12 Months
Rs. 7,625.00
Rs. 10,640.00
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Specifications
  • Shipping & Returns

Leuze HT25C.XL/4P-M12 Diffuse Sensor

The Leuze HT25C.XL/4P-M12 Diffuse Sensor, with part number 50139619, employs diffuse reflection with background suppression. It maintains a black-white error of less than 10% up to 350 mm and operates within specific ranges: 0 to 0.6 meters for white, 0.005 to 0.5 meters for gray, and 0.005 to 0.45 meters for black. Its adjustment range spans from 50 to 600 mm, featuring a divergent beam path and a red LED light source emitting at 640 nm.

The Leuze HT25C.XL/4P-M12 Diffuse Sensor utilizes a PNP transistor for switching, operating in both light and dark modes at a frequency of 1,000 Hz. It is equipped with a male M12 connector with 4 pins and is housed in ABS plastic. Operating temperatures range from -40 to 60 °C, with storage temperatures from -40 to 70 °C. Whether in manufacturing lines, automation systems, or quality control processes, the HT25C.XL/4P-M12 sensor delivers reliable and precise detection, contributing to improved efficiency and productivity.

Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, it’s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it’s important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on this site are the property of their respective owners. They are used solely for identification purposes and do not imply any endorsement or affiliation with our company.

IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!

Facebook, Youtube,


Product NumberHT25C.XL/4P-M12
Part Number50139619
Series25C
Operating PrincipleDiffuse reflection with background suppression
Black-White Error<10% up to 350 mm
Operating Range (Guaranteed)White 90%: 0–0.6 m
Gray 18%: 0.005–0.5 m
Black 6%: 0.005–0.45 m
Operating Range (Typical)0–0.6 m
Adjustment Range50–600 mm
Beam PathDivergent
Light SourceLED, Red
Wavelength640 nm
LED GroupExempt group (EN 62471)
Light Spot Size15 × 40 mm at 300 mm
Light Spot GeometryRectangular
Shift Angle±2° (typical)
Supply Voltage UB10–30 V DC (incl. residual ripple)
Residual Ripple0–15% of UB
Open-Circuit Current0–20 mA
Switching ElementTransistor, PNP
Switching PrincipleDark switching / Light switching
Switching Frequency1,000 Hz
Response Time0.5 ms
Readiness Delay300 ms
FunctionSignal OUT / Voltage supply
Type of ConnectionConnector
Thread SizeM12
Connector TypeMale
Connector MaterialPUR
Number of Pins4-pin
Connector EncodingA-coded
Dimension (W × H × L)15 × 42.7 × 30 mm
Housing MaterialPlastic, ABS
Lens Cover MaterialPlastic
Housing ColorRed
Type of FasteningThrough-hole mounting with M4 thread / optional mounting device
Material CompatibilityECOLAB
Type of DisplayLED
Operational ControlsMultiturn potentiometer
Function of Operational ControlRange adjustment
Ambient Temperature (Operation)-40 to 60 °C
Ambient Temperature (Storage)-40 to 70 °C
Degree of ProtectionIP67 / IP69K
Protection ClassIII
CertificationscUL US
Standards AppliedIEC 60947-5-2
