Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze GS61/6 Fork Photoelectric Sensor
Leuze

Leuze GS61/6 Fork Photoelectric Sensor

Product SKU: NTSSEN00282
Available:
Only 6 items in stock
6 items in stock
In stock
Pre-order
Out of stock
  • Brand : Leuze
  • Supply Voltage :  10 – 30 V, DC
  • Open-circuit current : 0 … 30 mA
  • No. of conductors  : 5 wire
  • Type of connection : Cable
  • Warranty : 12 Months
Rs. 6,485.00
Rs. 21,230.00
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Specifications
  • Shipping & Returns

Leuze GS61/6 Fork Photoelectric Sensor

The Leuze GS61/6 Fork Photoelectric Sensor (Part Number : 50110769) is a cutting-edge solution designed for precise detection of non-transparent labels. Ideal for high-speed industrial applications, this sensor boasts a compact and robust fork design (3 mm width, 41 mm depth) with a durable plastic housing and an IP65 protection rating. It utilizes an infrared LED light source with a wavelength of 940 nm, ensuring accurate detection of labels and gaps as small as 2 mm.

Engineered for performance, the sensor features a rapid switching frequency of 10,000 Hz and a response time of just 0.05 ms, making it suitable for fast-moving conveyor systems. The device includes a multiturn potentiometer for precise adjustments and dual LED indicators for real-time status updates. A versatile mounting system allows for easy installation using threads, through-holes, or optional mounting devices.

Operating reliably within a temperature range of -20°C to 60°C, the GS61/6 is equipped with a 2,000 mm cable connection and complies with IEC 60947-5-2 standards. The push-pull transistor switching output ensures compatibility with various industrial systems. Whether in packaging, labeling, or automated sorting, this sensor delivers unmatched precision and reliability.

Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, it’s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it’s important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on this site are the property of their respective owners. They are used solely for identification purposes and do not imply any endorsement or affiliation with our company.

IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!


Facebook, YouTube,


ParameterSpecification
Product NumberGS61/6
Part Number50110769
Series61
Principle of physicsOptical
ApplicationDetection of non-transparent labels
Label width, min.2 mm
Label gap, min.2 mm
MediumNot transparent
Light sourceLED, Infrared
Wavelength940 nm
Supply voltage UB10 ... 30 V, DC
Residual ripple0 ... 15 %, From UB
Open-circuit current0 ... 30 mA
TypeDigital switching output
Voltage typeDC
Switching current, max.100 mA
Switching voltagehigh: ≥(UB-2V), low: ≤2 V
Switching elementTransistor, Push-pull
Switching principleSwitching signal in label gap
Switching frequency10,000 Hz
Response time0.05 ms
Readiness delay300 ms
Max. conveyor speed during teach-in20 m/min
FunctionSignal OUT, Voltage supply
Type of connectionCable
Cable length2,000 mm
Number of conductors5-wire
DesignFork
Mouth width3 mm
Mouth depth41 mm
Dimension (W x H x L)11 mm x 30 mm x 60 mm
Housing materialPlastic
Plastic housingPC
Lens cover materialPlastic/PC
Housing colorBlack, RAL 9005; Red, RAL 3000
Type of fasteningMounting thread, Through-hole mounting, Via optional mounting device
Type of displayLED
Number of LEDs2 Piece(s)
Operational controlsMultiturn potentiometer
Ambient temperature, operation-20 ... 60 °C
Ambient temperature, storage-30 ... 70 °C
Degree of protectionIP 65
Protection classIII
Certificationsc UL US
Standards appliedIEC 60947-5-2
Country of originChina
