Kyocera TCG101WXLPAAFA-AA20 LCD Module

Kyocera TCG101WXLPAAFA-AA20 LCD Module

The Kyocera TCG101WXLPAAFA-AA20 LCD Module offers high-resolution WXGA (1280×800) imaging with a pixel density of 149 PPI, ideal for industrial and embedded applications. Featuring a wide active area of 216.96×135.6 mm, it delivers a brightness of 400 cd/m² and a contrast ratio of 800:1, ensuring crisp and vibrant visuals.

The display boasts a 160° wide viewing angle (80/80/80/80) and a response time of 8/22 ms (Tr/Td). With TN technology, WLED backlight (50K hours), and LVDS 20-pin interface, it ensures efficient and long-lasting performance. The panel is transmissive, has a glare surface with 2H hard coating, and supports 16.7M colors at 50% NTSC. Operating reliably between -20°C to 70°C, and storing between -30°C to 80°C, this display is engineered for demanding environments.

• It is a front polarizer. It may damaged. Please be cautious. Don’t scratch it.
• Always turn off the power supply when you are inserting or disconnecting it from the input connector.
• Wipe off water drop immediately as it may cause discoloration or spots.
• Please handle with great care. It may broken or cracked if dropped or bumped on hard surface.
• Do not try to open or modify the module assembly.
• At the insertion or removal of the Signal Interface Connector do not rotate or tilt the Interface Connector of the TFT Module. It may damage the panel.
• Severe temperature condition may  result in different luminance, response time.
