Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta DOP-107CV HMI Panel
Delta

Delta DOP-107CV HMI Panel

Product SKU: NTSHMI00009
Available:
Only 2 items in stock
2 items in stock
In stock
Pre-order
Out of stock
  • Model   :  DOP-107-CV,
  • Display Panel type   :  7″ TFT LCD (65535 colors),
  • Resolution   :  800 x 480 pixels,
  • Brightness   :  400 cd / m² (Typ.)
Rs. 14,840.00
Rs. 18,500.00
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Specifications
  • Shipping & Returns

Delta DOP-107CV HMI Operator Panel – Advanced Industrial Touchscreen Interface

The Delta DOP-107CV is a high-performance 7-inch HMI operator panel designed for industrial automation. Featuring a bright TFT LCD display with 800 x 480 resolution and 65535 colors, it ensures clear visibility in various lighting conditions. The LED backlight extends the display’s lifespan beyond 20,000 hours, making it a reliable choice for continuous industrial use.

Equipped with an ARM Cortex-A8 (800 MHz) processor, 256 MB Flash ROM, and 256 MB RAM, this HMI panel offers fast processing speed and efficient data handling. It supports multiple communication interfaces, including RS-232, RS-485, and RS-422, allowing seamless integration with industrial control systems. Additionally, it features USB Host and USB Slave ports for easy data transfer.

Designed for rugged environments, the IP65-rated front panel protects against dust and water, ensuring durability in industrial settings. The built-in buzzer, calendar, and multi-tone frequency alerts enhance functionality. It operates on a 24V DC power supply, consuming a maximum of 8.5W, making it an energy-efficient solution for automation needs.

With its compact design (215 x 161 x 61.2 mm) and easy installation, the Delta DOP-107CV is an excellent choice for machine monitoring, process control, and factory automation. Its shock and vibration resistance, along with CE & UL certifications, guarantee reliability in demanding applications.

Model DOP-107-CV
Display Panel type 7″ TFT LCD (65535 colors)
Resolution 800 x 480 pixels
Backlight LED Back Light (half-life under room temperature 25°C > 20,000 hours)*1
Display range 154.08 x 85.92 mm
Brightness 400 cd / m² (Typ.)
CPU ARM Cortex-A8 (800 MHz)
Flash ROM 256 Mbytes
RAM 256 Mbytes
Touchscreen 4-wire resistive touchscreen > 10,000,000 operated
Buzzer Multi-tone Frequency (2K – 4K Hz) / 80 dB
Network interface N/A 1 Port, 10 / 100 Mbps auto detection (built-in isolated circuit)*2
USB 1 USB Slave Ver. 2.0; 1 USB Host Ver. 2.0
SD N/A
Serial communication port

COM1 		RS-232 (supporting flow control)*2
COM2 RS-232 (supporting flow control) / RS-485*2
COM3 RS-422 / RS-485*2
Auxiliary function key N/A
Calendar Built-in
Cooling method Natural cooling
Approvals CE / UL (please use shielding network cable and magnetic ring with the filter of 300 ohm / 100 MHz)
Panel waterproof level IP65 / NEMA4 / UL TYPE 4X (indoor use only)
Operation voltage*2 DC +24V (-15% to +15%) (please use an isolated power supply)

Supplied by Class 2 or SELV circuit (isolated from MAINS by double insulation)
Leakage current 500 VAC for 1 minute (between DC24V terminal and FG terminal)
Power consumption*2 8.5 W (Max) *3 8.76 W (Max) *3
Backup battery 3V lithium battery CR2032 × 1
Backup battery life About 3 years or more at 25°C

(subject to operation temperature and condition)
Operation temperature 0°C to 50°C (32°F to 122°F)
Storage temperature -20°C to +60°C (-4°F to 140°F)
Operating environment 10% to 90% RH , 10% to 55% RH ;

pollution degree: 2
Vibration resistance Conforms to IEC61131-2: continuous vibration 5 Hz – 8.3 Hz with amplitude 3.5 mm; 8.3 Hz – 150 Hz with amplitude 1G
Shock resistance Conforms to IEC60068-2-27:

11 ms, 15 G Peak, in X, Y, Z directions each for 6 times
Dimension

(W) x (H) x (D) mm 		215 x 161 x 61.2
Mounting dimension

(W) x (H) mm 		196.9 x 142.9
Weight Approx. 970 g

Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, it’s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it’s important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on this site are the property of their respective owners. They are used solely for identification purposes and do not imply any endorsement or affiliation with our company.

IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!


Facebook, Youtube,


ModelDOP-107CV
Display Panel Type7" TFT LCD (65535 colors)
Resolution800 × 480 pixels
BacklightLED Back Light (half-life >20,000 hours at 25℃)
Display Range154.08 × 85.92 mm
Brightness400 cd/m² (Typ.)
CPUARM Cortex-A8 (800 MHz)
Flash ROM256 Mbytes
RAM256 Mbytes
Touchscreen4-wire resistive touchscreen (>10,000,000 operations)
BuzzerMulti-tone Frequency (2K–4K Hz) / 80 dB auto detection (isolated circuit)
USB1 USB Slave Ver. 2.0; 1 USB Host Ver. 2.0
SDN/A
Serial Communication PortCOM1 RS-232 (flow control), COM2 RS-232/RS-485, COM3 RS-422/RS-485
Auxiliary Function KeyN/A
CalendarBuilt-in
Cooling MethodNatural cooling
ApprovalsCE / UL (with shielding network cable + magnetic ring 300Ω / 100 MHz)
Panel Waterproof LevelIP65 / NEMA4
Operation VoltageDC +24V (-15% to +15%), isolated power supply (Class 2 / SELV, leakage current ≤500 VAC/1 min)
Power Consumption8.5 W (Max)
Backup Battery3V lithium battery CR2032 × 1
Backup Battery LifeAbout 3 years at 25℃ (subject to temperature and conditions)
Operation Temperature0℃ to 50℃ (32℉ to 122℉)
Storage Temperature-20℃ to +60℃ (-4℉ to 140℉)
Operating Environment10%–90% RH (0–40℃), 10%–55% RH (41–50℃); Pollution degree: 2
Vibration ResistanceIEC61131-2: 5–8.3 Hz, 3.5 mm amplitude; 8.3–150 Hz, 1G amplitude
Shock ResistanceIEC60068-2-27: 11 ms, 15 G Peak, X/Y/Z, 6 times each
Dimension (W×H×D) mm215 × 161 × 50
Mounting Dimension (W×H) mm196.9 × 142.9
