Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor
Leuze

Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor

Product SKU: NTSSEN00239
Available:
Only 5 items in stock
5 items in stock
In stock
Pre-order
Out of stock
  • Brand : Leuze
  • Supply Voltage :  10 – 30 V, DC
  • Open-circuit current : 0 … 20 mA
  • Switching element : Transistor, PNP
  • Type of connection : Connector M12
  • Warranty : 12 Months
Rs. 5,465.00
Rs. 7,250.00
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Specifications
  • Shipping & Returns

Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor

The Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor, identified by part number 50134215, offers a versatile adjustment range from 50 to 1,200 mm, catering to various application needs. Featuring a male M12 thread and a PUR cable with A-coded encoding, it ensures secure connections for reliable operation. With a compact dimension of 15 mm x 42.7 mm x 30 mm and a lightweight design , it facilitates easy installation and integration into industrial setups.

The Leuze HT25C/4P-M12 Diffuse Photoelectric Sensor has designed with user convenience in mind, the sensor includes operational controls such as a multiturn potentiometer for precise range adjustment. Its red housing color provides visibility and distinction, while the through-hole mounting with an M4 thread offers flexible installation options. The sensor's robust construction, with a plastic housing made of ABS and a plastic lens cover, ensures durability and longevity even in challenging environments. Its compliance with IP67 and IP69K protection standards, along with certification according to cULus and adherence to IEC 60947-5-2 standards, underscores its reliability and suitability for industrial applications.

Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, it’s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it’s important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on our site  are the property of their respective owners.

IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!

Facebook, Youtube,


Product Number
HT25C4P-M12
Part Number50134215
Series25C
Operating PrincipleDiffuse reflection with background suppression
Black-White Error< 10% up to 400 mm
Operating Range, GuaranteedWhite 90%: 0–1.2 m; Gray 18%: 0.005–0.75 m; Black 6%: 0.005–0.65 m
Operating Range, Typical0–1.2 m
Adjustment Range50–1,200 mm
Light SourceLED, Red
Wavelength640 nm
LED GroupExempt (per EN 62471)
Supply Voltage UB10–30 V DC, incl. residual ripple
Residual Ripple0–15 % from UB
Open-Circuit Current0–20 mA
Switching ElementTransistor, PNP
Switching PrincipleLight switching / Dark switching
Switching Frequency1,000 Hz
Response Time0.5 ms
Readiness Delay300 ms
FunctionSignal OUT, Voltage supply
Connection TypeConnector
Thread SizeM12
Connector TypeMale
Cable MaterialPUR
Number of Pins4-pin
EncodingA-coded
Dimensions (W x H x L)15 x 42.7 x 30 mm
Housing MaterialPlastic, ABS
Lens Cover MaterialPlastic
Housing ColorRed
FasteningThrough-hole mounting with M4 thread, or optional mounting device
Material CompatibilityECOLAB
Display TypeLED
Operational ControlsMultiturn potentiometer
Function of ControlRange adjustment
Ambient Temperature, Operation-40 to 60 °C
Ambient Temperature, Storage-40 to 70 °C
Degree of ProtectionIP67, IP69K
Protection ClassIII
Certificationsc UL US
Standards AppliedIEC 60947-5-2
