Hitachi SX14Q002-ZZA LCD Module with Touch

• Brand   :    Hitachi
• Size   :   5.7″
• Condition  :  New
• Panel Type   : CSTN-LCD, LCM
• Work Mode   : STN, Black (Negative), Transmissive

Hitachi SX14Q002-ZZA LCD Module with Touch

The Hitachi SX14Q002-ZZA LCD Module with Touch 5.7" CSTN-LCD display offers a 320×240 QVGA resolution with 70 PPI, providing a balanced visual experience for a variety of applications. With an active area of 115.2×86.4 mm, it offers sufficient space for detailed graphics and text display.

This display operates in Normally Black, Transmissive mode and uses an RGB vertical stripe panel treatment for vibrant color output. Although luminance, contrast ratio, and viewing angle specifications are not provided, the color support ensures good visual quality for applications requiring a colorful display.

The display uses a parallel data interface (1ch, 8-bit), which makes it easy to integrate into embedded systems. The backlight, powered by 1 pcs CCFL, helps illuminate the screen, though the lack of specific brightness and response time details means its performance in different lighting conditions and dynamic content is uncertain.

• It is a front polarizer. It may damaged. Please be cautious. Don’t scratch it.
• Always turn off the power supply when you are inserting or disconnecting it from the input connector.
• Wipe off water drop immediately as it may cause discoloration or spots.
• Please handle with great care. It may broken or cracked if dropped or bumped on hard surface.
• Do not try to open or modify the module assembly.
• At the insertion or removal of the Signal Interface Connector do not rotate or tilt the Interface Connector of the TFT Module. It may damage the panel.
• Severe temperature condition may  result in different luminance, response time.
