BOE BA121S01-200 LCD Module

BOE BA121S01-200 LCD Module

The BOE BA121S01-200 LCD Module is a 12.1-inch a-Si TFT-LCD panel offers a resolution of 800(RGB)×600 SVGA with an 82 PPI pixel density, providing clear and detailed visuals. Its active area measures 246(W)×184.5(H) mm, and the outline dimensions are 279(W)×209(H)×9.3(D) mm, making it suitable for various applications.

With a luminance of 400 cd/m² and a contrast ratio of 800:1 (typical), the panel delivers vibrant colors and sharp contrasts. Its viewing angles of 80/80/65/75 degrees ensure good visibility from different directions, while the response time of 30 ms (Tr+Td) ensures smooth image transitions.

The panel operates in a TN (Twisted Nematic), Normally White, Transmissive mode. It supports 262K or 16.7M colors with 55% NTSC color coverage, offering great color depth.

It uses an LVDS (1 ch, 6/8-bit) interface with a 20-pin connector, operates at 3.3V, and comes with a WLED backlight rated for 30,000 hours and equipped with an LED driver. The panel is designed to function in temperatures from -20°C to 70°C and can be stored between -30°C and 80°C.

• It is a front polarizer. It may damaged. Please be cautious. Don’t scratch it.
• Always turn off the power supply when you are inserting or disconnecting it from the input connector.
• Wipe off water drop immediately as it may cause discoloration or spots.
• Please handle with great care. It may broken or cracked if dropped or bumped on hard surface.
• Do not try to open or modify the module assembly.
• At the insertion or removal of the Signal Interface Connector do not rotate or tilt the Interface Connector of the TFT Module. It may damage the panel.
• Severe temperature condition may  result in different luminance, response time.
