BTH BU-15K U-Shape Photo Sensor
5 in stock
- Brand : BTH
- Slot Width : 15 mm
- Operating Voltage : 12 ~ 24 VDC
- Output type : PNP(NO) Dark on / PNP(NC) Light on / NPN(NO) Dark on / NPN(NC) Light on
₹2,145.00 ₹2,917.00 GST Extra
5 in stock
BTH BU-15K U-Shape Photo Sensor
The BTH BU-15K is a U-Shape Photo Sensor engineered for accurate detection of small opaque objects down to Ø0.5 mm. With a 15 mm slot width, it utilizes a 940 nm infrared LED to deliver stable, non-contact sensing in a wide range of industrial applications. It supports PNP/NPN, NO/NC, and light-on/dark-on modes, offering flexible system compatibility.
Operating at 12–24 VDC, it draws a maximum of 18 mA and handles up to 100 mA load current. Its 1 ms response time ensures reliable performance in high-speed processes. Built from durable PC material, the BU-15K is rated IP64 for protection against dust and splashes. It resists shock (50G) and vibration across all axes, and performs reliably in temperatures from -10°C to +55°C. The sensor comes pre-wired with a 2 m cable for simple installation.
Our engineers actively inputted all the required details of this item in accordance with the datasheet. Nevertheless, it’s imperative to recognize that errors may arise during this process. Despite our sincere efforts, it’s important to remain cautious. Nonetheless, inaccuracies can still occur. All trademarks and trade names used on this site are the property of their respective owners. They are used solely for identification purposes and do not imply any endorsement or affiliation with our company.
IndustryShoppy.in is your one-stop destination for all industrial automation needs. With a vast array of products including sensors, HMIs, PLCs, and more, we cater to diverse industries with top-quality solutions. Our user-friendly platform ensures a seamless shopping experience, while our commitment to reliability and customer satisfaction sets us apart. Explore our comprehensive range and elevate your operations with IndustryShoppy.in today!
| Weight | 340 g |
|---|---|
| Dimensions | 20 × 18 × 10 cm |
| Brands | BTH |
| Condition | New |
| Warranty | 12 Months |
| Brand | BTH |
| Product Number | BU-15K |
| Type | Photo Sensor |
| Slot Width | 15 mm |
| Min. detection object | Opaque (Ø0.5 x 10.0 mm) |
| Emitting light | Infrared LED 940nm |
| Operating Voltage | 12 ~ 24 VDC |
| Current Consumption | 18 mA Max. |
| Load current | 100mA Max. at 24VDC |
| Output type | PNP(NO) Dark on / PNP(NC) Light on / NPN(NO) Dark on / NPN(NC) Light on |
| Response time | 1 ms Max. |
| Ambient illumination | Incandescent light / 1,000 lux max. |
| Insulation resistance | 20MΩ min. (DC500V) |
| Voltage with standabiligy | AC500V 60Hz for 60 Sec. |
| Operating temperature | -10°C ~ + 55°C |
| Ambient humidity | 45% ~ 85% RH |
| Protection degree | IP64 |
| Vibration resistance | 1.5-mm peak-to-peak amplitude, 10 to 55 Hz, 2 hours each in X, Y, and Z directions |
| Shock resistance | 50G, repeated 10 times each in X, Y, and Z directions |
| Material | PC |
| Wiring method | Pre-wired Ø4.2 x 2 M / 3-wires |
